Arkansas Department of Transportation
- 10324 Interstate 30
- Little Rock, Arkansas 72209
- Monday – Friday 8:00 AM – 4:30 PM
- Permits Phone:(501) 569-2381
Monday – Friday 6:00 AM – 4:30 PM - Email: ahppermit@ardot.gov
- Online Permits: Click Here
- Permit Rules: Click Here
Operating Hours, Restricted Travel, and Holiday Restrictions:
- Load Movement: Daylight Hours
- Movement Times: 30 minutes before sunrise to 30 minutes after sunset.
- Operating Times: Continuous travel may be allowed if over width only, not to exceed 108,000 Lbs. Loads not exceeding 90′ long (other legal dimensions) may have continuous travel.
- Restricted Travel
Oversize movements through the metropolitan Little Rock area between the hours of 7:00 AM – 9:00 AM and 4:00 AM – 6:00 PM, and on I-30 (M.M. 138-143), I-40 (M.M. 151-155), and all I-630 are strictly prohibited. No travel on major holidays (New Years, Memorial Day, Independence Day, Labor Day, Thanksgiving and Christmas). If the holiday falls on Monday or Friday, no weekend movement is allowed.
Legal Dimensions:
- Length: 53′ 6″
- Width: 8′ 6″
- Height: 13′ 6″
- Weight: 80,000 lbs.
Routine Permit Limits:
- Length: None
- Width: 16′, 20′ on some non-interstate routes
- Height: 17′, Loads that exceed 16′ must obtain special approval and not be allowed on Interstates. Utilities personnel must accompany load over 17’.
Note: Loads exceeding 14′ in Width and 15′ in Height are evaluated on a case-by-case basis to determine if route survey is required.
Weight:
- Single: 20,000 Lbs.
- Tandem: 46,000 Lbs.
- Tridem: 60,000 Lbs.
- Quad: 68,000 Lbs.
Steer Axle: Arkansas request manufacturer’s front axle weight rating (up to maximum of 20,000 pounds.
Signs, Flags, and Lights Requirements
Signs, flags, and lights may be required when moving oversize loads or super loads for the safety of others on the road.
Signs
“Oversize Load” signs are required on all loads that exceed legal dimensions, except for overweight-only loads. These signs must be displayed at both the front and rear of the vehicle. The signs should be made of reflective material and be clearly visible to other drivers. They must have black letters on a yellow background, with letters at least 10” tall and 1.5” wide.
Flags
Flags are required on oversized loads to signal the vehicle’s extended dimensions. In Arkansas, red or orange warning flags (18” Square) should be placed at the extremities of the load:
- (4) flags are required if the load exceeds the vehicle’s width.
- (1) flag must be placed at each corner of the load.
- Additional flags may be necessary if the load extends more than (4”) beyond the rear of the vehicle.
Lights
The state of Arkansas does not specify light requirements for oversized loads, so lighting requirements ultimately adhere to federal guidelines.
Arkansas Pilot Car Requirements:
- Length: Loads exceeding 75′ to 95′ require (1) rear pilot car on (2) lane roads.
- Width: Loads exceeding 10’6″ to 12′ wide on 2-lane roads require one front pilot car. Load widths of (12’1″ to 14′) require (1) front and (1) rear pilot car on all (2) lane roads, and (1) rear pilot car on all (4) lane roads. Load widths of (14’1″ to 15′) require (1) front and (1) rear pilot car.
- Height: Loads exceeding 15′ require a Height Pole.
- Weight: Check with the state for weight-related pilot car requirements.
Overhang: Loads with front or rear overhangs exceeding (10′) may require pilot cars.
Note: Police escorts for larger loads are looked at on a case-by-case basis.
